We Have H59，C2800(H62)，C2680(H65)，C2620(H68)，C2600(H70)，C2200(H90) Brass Strip .Thickness ≥ 0.01mm ,Width ≥ 2mm
| Alloy | Chemical Component(%) | ||||||
| QB | GB/JIS/UNS | Cu | Pb | Zn | Fe | Sn | Other |
| H62 | H62/JIS C2720 | 60.5-63.5 | <=0.08 | REM | <=0.15 | - | <=0.5 |
| H65 | H65/JIS C2680 | 63.5-68.0 | <=0.03 | REM | <=0.1 | - | <=0.3 |
| H70 | C2600 | 68.5-71.5 | <=0.03 | REM | <=0.5 | - | <=0.1 |
| H80 | C2400 | 79-81 | <=0.03 | REM | <=0.5 | - | <=0.1 |
| H90 | H90 | 88.0-91.0 | <=0.03 | REM | <=0.1 | - | <=0.1 |
| H96 | H96 | 95.0-97.0 | <=0.03 | REM | <=0.1 | - | <=0.2 |
| Mechanical Property | |||||||
| Alloy | Temper | Tensile Strength (Mpa) | Elongation(%) | ||||
| H62 | Y2(1/2H) | >=410 | >=7 | ||||
| Y(H) | 685-980 | ||||||
| H65 | Y2(1/2H) | >=400 | >=7 | ||||
| Y(H) | 635-885 | - | |||||
| H68 | Y2(1/2H) | >=390 | >=10 | ||||
| Y(H) | 685-930 | - | |||||
| H90 | Y(H) | 470-800 | - | ||||
| H96 | |||||||
